X-Ray Tube Heating and Cooling
Perry Sprawls, Ph.D.

Online Textbook

Table of Contents



INTRODUCTION AND OVERVIEW
HEAT PRODUCTION
HEAT CAPACITY
FOCAL SPOT AREA
    Focal Spot Size
    Anode Angle
    Anode Rotation Speed
    KV Waveform
ANODE BODY
TUBE HOUSING
CLINICAL APPLICATIONS



INTRODUCTION AND OVERVIEW

CONTENTS

   To produce x-radiation, relatively large amounts of electrical energy must be transferred to the x-ray tube. Only a small fraction (typically less than 1%) of the energy deposited in the x-ray tube is converted into x-rays; most appears in the form of heat. This places a limitation on the use of x-ray apparatus. If excessive heat is produced in the x-ray tube, the temperature will rise above critical values, and the tube can be damaged. This damage can be in the form of a melted anode or a ruptured tube housing. In order to prevent this damage, the x-ray equipment operator must be aware of the quantity of heat produced and its relationship to the heat capacity of the x-ray tube.

The heat produced during x-ray production can be a limiting factor:

  • In the use of small focal spots that are desirable for good image detail, one example is magnification mammography.

  • In CT, especially with spiral scanning of relatively large anatomical regions.

One of the major challenges in developing x-ray tubes for modern, high performance, CT systems is to provide design features to accommodate the high levels of heat produced.

   The figure below identifies the factors that affect both heat production and heat capacity.


Factors That Determine the Amount of Heat Produced and the
Three Areas of an X-Ray Tube That Have Specific Heat Capacities



  HEAT PRODUCTION

CONTENTS

    Heat is produced in the focal spot area by the bombarding electrons from the cathode. Since only a small fraction of the electronic energy is converted in x-radiation, it can be ignored in heat calculations. We will assume all of the electron energy is converted into heat. In a single exposure, the quantity of heat produced in the focal spot area is given by

Heat (J) = KVe x MAS

or

Heat (J) = w x KVp x MAS.

Where  KV  is the effective KV value and KVp is the peak KV value.

   In this relationship, w is the waveform factor; its value is determined by the waveform of the voltage applied to the x-ray tube. Values for most waveforms encountered in diagnostic x-ray machines are: constant potential, 1.0; three-phase, 12 pulse, 0.99; three-phase, 6-pulse, 0.96; single-phase, 0.71.

   Although the joule is the basic unit for energy and heat, it is not always used to express x-ray tube heat. The special heat unit (HU) was introduced when single-phase equipment was common to make it easy to calculate heat.


 The relationship between a quantity of heat expressed in heat units and in joules is given by

Heat (HU) = 1.4 x heat (J).

Note: A heat unit is a smaller quantity of heat than a joule since one joule is equal to 1.4 heat units.

   Since the product of the joules-to-heat unit conversion factor (1.4) and the waveform factor for single-phase (0.71 ) is equal to 1, the following relationship is obtained:

Heat (HU) = KVp x MAS.

   Here it is seen that for single-phase operation, the heat produced in heat units is the product of the KVp and MAS. In fact, this is why the heat unit is used. In the earlier days of radiology, when most equipment was single-phase, it was desirable to calculate heat quantities without having to use a waveform factor. This was achieved by introducing a new unit, the heat unit. For three-phase, six-pulse equipment, the heat in heat units is given by

Heat (HU) = 1.35 x KVp x MAS.

The factor of 1.35 is the ratio of the waveform factors, 0.96/0.71.

The rate at which heat is produced in a tube is equivalent to the electrical power and is given by

Power (watts) = w x KVp x MA.

The total heat delivered during an exposure, in joules or watt-seconds, is the product of the power and the exposure time.



HEAT CAPACITY

CONTENTS

   In order to evaluate the problem of x-ray tube heating, it is necessary to understand the relationship of three physical quantities: (1) heat, (2) temperature, and (3) heat capacity. Heat is a form of energy and can be expressed in any energy units. In x-ray equipment, heat is usually expressed in joules (watt-seconds) or heat units.

   Temperature is the physical quantity associated with an object that indicates its relative heat content. Temperature is specified in units of degrees. Physical changes, such as melting, boiling, and evaporation, are directly related to an object's temperature rather than its heat content.

   For a given object, the relationship between temperature and heat content involves a third quantity, heat capacity, which is a characteristic of the object. The general relationship can be expressed as follows:

Temperature = heat / heat capacity.

   The heat capacity of an object is more or less proportional to its size, or mass, and a characteristic of the material known as the specific heat. As heat is added to an object, the temperature increases in proportion to the amount of heat added. When a given amount of heat is added, the temperature increase is inversely proportional to the object's heat capacity. In an object with a large heat capacity, the temperature rise is smaller than in one with a small heat capacity. In other words, the temperature of an object is determined by the relationship between its heat content and its heat capacity. This is illustrated below.


Relationship Among Heat, Temperature, and Heat Capacity

   In x-ray tube operation, the goal is never to exceed specific critical temperatures that produce damage. This is achieved by keeping the heat content below specified critical values related to the tube's heat capacity.

   In most x-ray tubes there are three distinct areas with critical heat capacities, as shown below. The area with the smallest capacity is the focal spot area, or track, and is the point at which heat is produced within the tube. From this area, the heat moves by conduction throughout the anode body and by radiation to the tube housing; heat is also transferred, by radiation, from the anode body to the tube housing. Heat is removed from the tube housing by transfer to the surrounding atmosphere. When the tube is in operation, heat generally flows into and out of the three areas shown. Damage can occur if the heat content of any area exceeds its maximum heat capacity.



The Three Critical Heat Capacities in an X-Ray Tube



FOCAL SPOT AREA

CONTENTS

   The maximum heat capacity of the focal spot area, or track, is the major limiting factor with single exposures. If the quantity of heat delivered during an individual exposure exceeds the track capacity, the anode surface can melt, as shown below.


A Rotating Anode Damaged by Overheating

The capacity of a given focal spot track is generally specified by the manufacturer in the form of a graph, as shown below. The curves on the graph show the maximum power (KV and MA) that can be delivered to the tube for a given exposure time without producing overload. Graphs of this type are generally designated tube rating charts. From this graph, it is seen that the safe power limit of a tube is inversely related to the exposure time. This is not surprising, since the total heat developed during an exposure is the product of power and exposure time. It is not only the total amount of heat delivered to the tube that is crucial, but also the time in which it is delivered.



Rating Charts for an X-Ray Tube Operated under Different Conditions
(Focal Spot Size, Rotation Speed, and KV Waveform)

   X-ray tubes are often given single power ratings (in kilowatts, kW). By general agreement, an exposure time of 0.1 second is used for specifying a tube's power rating. Although this does not describe a tube's limitations at other exposure times, it does provide a means of comparing tubes and operating conditions.

The significance of a power rating is that it specifies the maximum rate (how fast) energy can safely be applied to a tube.  This can limit how short exposure times can be made to reduce motion blurring because a short exposure time requires a higher power (increased MA) to produce the necessary exposure.

   A number of different factors determine the heat capacity of the focal spot track. The focal spot track is the surface area of the anode that is bombarded by the electron beam. In stationary anode tubes, it is a small area with dimensions of a few millimeters. In the rotating anode tube, the focal spot track is much larger because of the movement of the anode with respect to the electron beam. The figure below shows a small section of a rotating anode.



Section of a Rotating Anode Showing Relationship
of Focal Spot Track to Electron Beam and Anode Angle


Focal Spot Size

CONTENTS

   From the standpoint of producing x-ray images with minimum blur, a small focal spot is desired. However, a small focal spot tends to concentrate heat and give the focal spot track a lower heat capacity. The only advantage of a larger focal spot is increased heat capacity. Many x-ray tubes have two focal spot sizes that can be selected by the operator. The small focal spot is generally used at relatively low power (KV and MA) settings. The large focal spot is used when the machine must be operated at power levels that exceed the rated capacity of the small focal spot. The specified size of an x-ray tube focal spot is the dimensions of the effective or projected focal spot shown in the figure above. Notice that the actual focal spot, the area bombarded by the electron beam, is always larger than the projected, or effective, focal spot. For a given anode angle, the width of the focal spot track is directly proportional to the size of the projected spot. The relationship between heat capacity and specified focal spot size is somewhat different. In many tubes, doubling the focal spot size increases the power rating by a factor of about 3.



Anode Angle

CONTENTS

   The actual relationship between focal spot width (and heat capacity) and the size of the projected focal spot is determined by the anode angle. Anode angles generally range from about 7 to 20. For a given effective focal spot size, the track width and heat capacity are inversely related to anode angle. Although anodes with small angles give maximum heat capacity, they have specific limitations with respect to the area that can be covered by the x-ray beam. X-ray intensity usually drops off significantly toward the anode end because of the heel effect. In tubes with small angles, this is more pronounced and limits the size of the useful beam. The figure below shows the nominal field coverage for different anode angles. When specifying an x-ray tube for purchase, the anode angle should be selected by a compromise between heat capacity, especially for smaller focal spots, and field of coverage.



Variation of X-Ray Intensity and Maximum X-ray Beam Size Because of the Anode Heel Effect



  Anode Rotation Speed

CONTENTS

   In rotating tubes, the anode assembly is mounted on bearings and actually forms the rotor of an electric motor. The x-ray tube is surrounded by a set of coils that form the stator of the motor. When the coils are energized from the power line, the rotor spins. The speed of rotation is determined by the frequency of the applied current. When the stator coils are operated from the 60-Hz power line, the speed of rotation is approximately 3,000 rpm. By using a power supply that produces 180-Hz current, rotation speeds of approximately 10,000 rpm can be obtained. This is commonly referred to as high-speed rotation.

   The effective length of the focal spot track is proportional to the speed of rotation for a given exposure time. High-speed rotation simply spreads the heat over a longer track, especially in short exposure times. High-speed rotation generally increases the power capacity of a tube by approximately 60%.



KV Waveform

CONTENTS

   Another factor that affects the heat capacity of the focal spot track is the waveform of the KV. Single-phase power delivers energy to the anode in pulses, as shown below. Three-phase and constant potential generators deliver the heat at an essentially constant rate, as indicated. The figure below compares the temperatures produced by a single-phase and a constant potential machine delivering the same total heat. Because of the pulsating nature of single-phase power, some points on the anode surface are raised to higher temperatures than others. These hot spots exceed the temperature produced by an equal amount of three-phase energy. When an x-ray tube is operated from a single-phase power supply, the maximum power must be less than for constant potential operation to keep the hot spots from exceeding the critical temperature. In other words, constant potential operation increases the effective focal spot track heat capacity and rating of an x-ray tube.



Approximate Distribution of Temperature along the Focal Spot Track
for Single-Phase and Three-Phase Operation

   The effect of KV waveform on tube rating should not be confused with the effect of waveform on heat production, which was discussed earlier. However, both factors should be considered to determine if there is any advantage, from the standpoint of tube heating, to using three-phase or constant potential power. In comparing three-phase or constant potential and single-phase operation, three factors should be considered:

1. Constant potential operation permits a tube to be operated at a higher power level because of the uniform distribution of heat.

2. Constant potential operation produces more x-radiation and increased penetration at a given KV  and MAS setting.

3. Constant potential operation produces more heat for a given KV and MAS setting.

   The real advantage of constant potential operation is related to the first two factors. Because of the increased efficiency of x-ray production, and the increased penetrating ability of the radiation, a lower KV or MAS value is required to produce a given film exposure. This more than compensates for the increased heat production associated with constant potential operation. The increased rating, or maximum permissible power, associated with the constant potential waveform also adds to the advantage. An x-ray tube can generally be operated at a higher power level when the power is supplied from a three-phase or constant potential power supply, and it will also produce radiation more efficiently.

   A rating chart for an x-ray tube operated at different waveforms and rotation speeds is shown in the figure titled, Rating Curves for an X-Ray Tube Operated under Different Conditions. The highest power capacity is obtained by using three-phase power and high-speed rotation; notice that the real advantage occurs at relatively short exposure times. As exposure time is increased, overlapping of the focal spot track and the diffusion of heat make the difference in power capacity much less significant.

   The actual rating charts supplied by an x-ray tube manufacturer are shown in the figure referred to in the previous paragraph. It is common practice for each of the four operating conditions (wave-form and speed) to be on a separate chart. Each chart contains a number of different curves, each representing a different MA value. The vertical scale on such a rating chart is KV. A chart of this type is still a power rating chart. Each combination of KV and MA represents a constant power value. Such a chart is easier to use, since it is not necessary to calculate the power. The rating chart is used by the operator to determine if the technical factors, KV, MA, and exposure time, for a given exposure will exceed the tube's rated capacity.

   Most rotating anode tubes contain two focal spots. As mentioned previously, the size of the focal spot significantly affects the heat capacity. Remember that a given x-ray tube has a number of different rating values, depending on focal spot size, rotation speed, and waveforms. Some typical values are shown in the table below.

Heat Rating (in Joules) for Typical X-Ray Tube
for Exposure Time of 0.1 sec and
 Focal Spot Sizes of 0.7 mm and 1.5 mm



Single-phase

Three-phase

3,600 rpm

700 (0.7 mm)

1,050 (0.7 mm)

2,300 (1.5 mm)

3,400 (1.5 mm)

10,800 rpm

1,100 (0.7 mm)

1,700 (0.7 mm)

3,900 (1.5 mm)

5,800 (1.5 mm)



ANODE BODY

CONTENTS

   The heat capacity of the focal spot track is generally the limiting factor for single exposures. In a series of radiographic exposures, CT scanning, or fluoroscopy, the build-up of heat in the anode can become significant. Excessive anode temperature can crack or warp the anode disc. The heat capacity of an anode is generally described graphically, as shown below. This set of curves, describing the thermal characteristics of an anode, conveys several important pieces of information. The maximum heat capacity is indicated on the heat scale. The heating curves indicate the build-up of heat within the anode for various energy input rates. These curves apply primarily to the continuous operation of a tube, such as in CT or fluoroscopy. For a given x-ray tube, there is a critical input rate that can cause the rated heat capacity to be exceeded after a period of time. This is generally indicated on the graph. If the heat input rate is less than this critical value, normal cooling prevents the total heat content from reaching the rated capacity.



Anode Heating and Cooling Curves

   The cooling curve can be used to estimate the cooling time necessary between sets of exposures. Suppose a rapid sequence of exposures has produced a heat input of 90,000 HU. This is well over 50% of the anode storage capacity. Before a similar sequence of exposures can be made, the anode must cool to a level at which the added heat will not exceed the maximum capacity. For example, after an initial heat input of 90,000 HU, a cooling time of approximately 3.5 minutes will decrease the heat content to 30,000 HU. At this point, another set of exposures producing 90,000 HU could be taken.

   The cooling rate is not constant. An anode cools faster when it has a high heat content and a high temperature. In CT scanning, when anode heating is a limiting factor, a higher scan rate can be obtained by operating the anode with the highest safe heat content since the cooling rate is higher for a hot anode and more scans can be obtained in a specific time than with a cool anode.

 Most CT systems have a display that shows the anode heat content as a percentage of the rated capacity during and after a scan.

   The anodes in most radiographic equipment are cooled by the natural radiation of heat to the surrounding tube enclosures. However, anodes in some high powered equipment, such as that used in CT, are cooled by the circulation of oil through the anode to a heat exchanger (radiator).

   Anode damage can occur if a high-powered exposure is produced on a cold anode. It is generally recommended that tubes be warmed up by a series of low energy exposures to prevent this type of damage.



TUBE HOUSING

CONTENTS

   The third heat capacity that must be considered is that of the tube housing. Excessive heat in the housing can rupture the oil seals, or plugs. Like the anode, the housing capacity places a limitation on the extended use of the x-ray tube, rather than on individual exposures. Since the housing is generally cooled by the movement of air, or convection, its effective capacity can be increased by using forced air circulation.

   The housing heat capacity is much larger than that of the anode and is typically over 1 million HU. The time required for a housing to dissipate a given quantity of heat can be determined with cooling charts supplied by the manufacturer.



CLINICAL APPLICATIONS

CONTENTS

   The heat characteristics of x-ray tubes should be considered when tubes are selected and specified for specific clinical applications and should be used as a guide to proper tube operation.

It is often the heat in the focal spot that limits the use of small focal spots that are desirable for good image detail.

The rapid accumulation of heat (because of high power operation) in the anode can be a limiting factor in CT.  It depends on the design characteristics of the tube.

Many x-ray systems, including CT, have built-in safety features that will not allow the equipment to be operated in an "overheated" condition.
